Specs
Mower Dimensions
| Length | 87″-91.25″ |
| Width (chute down) | 73.5″ |
| Width (chute in transport position) | 62.75″ |
| Height (ROPS folded) | 49.5″ |
| Height (ROPS up) | 67″ |
| Weight | 1,364-1,392 lb |
General Specifications
| Total Fuel Capacity | 13 gallons |
| Caster Tires | 13″ x 6.5″-6″ |
| Seat | 4-point iso-mounted mid-back mounted on operator-suspension platform |
Drive System Specifications
| Drive System Type | Hydro-Gear ZT5400 Transaxle. Two-Speed |
| Pumps | Internal Pump: 16 cc |
| Motors | Internal Motor: 21 cc |
| Forward Ground Speed | 16 mph (high-speed) 12 mph (low-speed) |
| Reverse Ground Speed | 8 mph (high-speed) 5 mph (low-speed) |
| Parking Brake | Foot-operated pedal |
Deck Specifications
| Cutting Widths | 61″ |
| Type | Velocity Plus™ |
| Cutting Height | 1.25″ to 5″ in .25″ increments |
| Deck Lift | Adjustable foot-operated pedal |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Ogura GT5 (350 ft lb) Adjustable air-gap for extended life. |
