Specs
Engine
| Engine Options | Vanguard EFI |
| Power | 37hp |
Dimensions
| Tracking Width | 48″ |
| Height (ROPS up) | 47.25″ |
| Weight | 1,000-1,022 lb |
| Length | 69.5″ |
| Height (ROPS folded) | 53.75″ |
| Width (chute in transport position) | 65.25″ |
| Width (chute down) | 48″ |
General Specifications
| Total Fuel Capacity | 8 gallons |
| Drive Tires | 24″ x 12″-12″ Flat Free Airless |
| Caster Tires | 3″ x 5″-6″ |
| Seat | Extra-large comfort cushion |
Drive System Specifications
| Drive System Type | Dual Pump and Motor |
| Pumps | Hydro-Gear 12 cc |
| Motors | Parker 14 ci |
| Forward Ground Speed | 10.5 mph |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Hand lever |
Deck Specifications
| Cutting Widths | 52″ |
| Type | Velocity Plus™ |
| Cutting Height | 1.5″ to 4.5″ in .25″ increments |
| Deck Lift | Hand lever |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Ogura GT3.5 (250 ft lb) Adjustable air-gap for extended life. |
