Specs
Engine Model
5901752
US MSRP ^
CAN MSRP ^
RPM
Full Speed: 3750 RPM (No load) Idle: 1400 RPM
Fuel Capacity - gal (L)
2.5 (9.5 L)
Fuel Type
Regular unleaded gasoline, 87 octane or higher
Fuel Shut-Off Valve
Located on engine and below tank
Transmission Model
Peerless 855 Series, coated for corrosion resistance
Speed (mph)
Low Gear: 3.5 mph (5.6 km/hr) High Gear: 5.0 mph (8.0 km/hr)
Front Tires
18 x 9.5 - 8, RV antifreeze added for ballast and traction
Rear Tires
13 x 6.50 - 6
Spreader Model
Spyker 120 Series
Spreader Hopper Capacity (lbs.)
100
Spray Pump
2.0 gpm mechanically driven diaphragm pump
Sprayer Tank Capacity - gal (L)
12.0 (45.4)
Nozzles
Broadcast: Turbo FloodJet TF-VS5 Trim: Turbo TeeJet TT11004VP
Spray Rate
1/4 gallon per 1,000 ft² at 20 psi
Productivity (sq. ft. per fill)
48,000 (1/4 gallon per 1,000 ft² at 25 psi at 5 mph)
Overall Length - in. (cm)
54.0 (137)
Overall Width - in. (cm)
35.5 (90)
Overall Height - in. (cm)
49.0 (124)
Dry Weight - lbs (kg)
420 (190)
Full Weight - lbs (kg)
640 (290)
Safety Interlock
This machine is equipped with a neutral safety start module. To start the engine, the transmission must be in the neutral (N) position.
Accessories Warranty
Standard: 1 year Rental: 90 days
Belts, Tires, Brake Pads, Hoses, Battery Warranty
Standard: 90 days Rental: 90 days
Engine Brand
Honda® GX200-URH2
Legacy Material Number
5902208
Operator's Manuals
^ Suggested prices will vary by market. Price shown in US dollars. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
Engine Model
5902208
US MSRP ^
$11,274.00
CAN MSRP ^
$15,220.00
RPM
Full Speed: 3750 RPM (No load) Idle: 1400 RPM
Fuel Capacity - gal (L)
2 (7.5)
Fuel Type
Regular unleaded gasoline, 87 octane or higher
Fuel Shut-Off Valve
Located on engine and below tank
Transmission Model
Peerless 855 Series, coated for corrosion resistance
Speed (mph)
Low Gear: 3.5 mph (5.6 km/hr) High Gear: 5.0 mph (8.0 km/hr)
Front Tires
18 x 9.5 - 8, RV antifreeze added for ballast and traction
Rear Tires
13 x 6.50 - 6
Spreader Model
Spyker 120 Series
Spreader Hopper Capacity (lbs.)
100
Spray Pump
2.0 gpm mechanically driven diaphragm pump
Sprayer Tank Capacity - gal (L)
12.0 (45.4)
Nozzles
Broadcast: Turbo FloodJet TF-VS5 Trim: Turbo TeeJet TT11004VP
Spray Rate
1/4 gallon per 1,000 ft² at 20 psi
Productivity (sq. ft. per fill)
48,000 (1/4 gallon per 1,000 ft² at 25 psi at 5 mph)
Overall Length - in. (cm)
54.0 (137)
Overall Width - in. (cm)
35.5 (90)
Overall Height - in. (cm)
49.0 (124)
Dry Weight - lbs (kg)
420 (190)
Full Weight - lbs (kg)
640 (290)
Safety Interlock
This machine is equipped with a neutral safety start module. To start the engine, the transmission must be in the neutral (N) position.
Accessories Warranty
Standard: 1 year Rental: 90 days
Belts, Tires, Brake Pads, Hoses, Battery Warranty
Standard: 90 days Rental: 90 days
Wands
Push-to-Connect Spray Wand; Tooless hose installation/removal Including spot spray wand std. - 4ft hose.
Engine Brand
Honda® GX200-URH2
Legacy Material Number
5902208
Operator's Manuals
^ Suggested prices will vary by market. Price shown in US dollars. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
