Specs
Right Hand Throttle, MKIII, NA 970 49 91‑01 | |
|---|---|
Equipment | |
Nozzle type | Round |
Harness | Integrated |
Vacuum Kit | No |
Right Hand Throttle, MKIII, NA 970 49 91‑01 | |
|---|---|
Engine | |
Cylinder displacement | 75.6 cm³ |
Output shaft power1 | 4.6 hp |
Fuel tank volume | 87.92 fl oz (US) |
Fuel Consumption | 464 g/kWh |
Maximum power speed | 7,450 rpm |
Idling speed | 2,000 rpm |
Electrode gap | 0.03 in |
Right Hand Throttle, MKIII, NA 970 49 91‑01 | |
|---|---|
Capacity | |
Max Blow force | 47 N |
Max air flow at nozzle (round) | 1,000 cfm |
Max Air speed (Round nozzle) | 220 mph |
Right Hand Throttle, MKIII, NA 970 49 91‑01 | |
|---|---|
Dimensions | |
Weight | 26.8 lbs |
Product size height | 21.61 in |
Product size length | 12.76 in |
Product size width | 20.24 in |
Tube diameter | 3.386 in |
Tube length | 47.126 in |
Right Hand Throttle, MKIII, NA 970 49 91‑01 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear (LpA) | 106 dB(A) |
Sound power level, measured | 113 dB(A) |
Sound power level, guaranteed (LWA) | 115 dB(A) |
