Specs
12" SN 3/8" mini 1,3 mm S93G SKU: 970 73 72‑12 | ||
|---|---|---|
| Engine | 12" SN 3/8" mini 1,3 mm S93G SKU: 970 73 72‑12 | 12" SN 3/8 mini" 1,3 mm S93G SKU: 967 63 33‑12 |
| Chain speed at max power | 59.38 fts | 59.4 fts |
| Cylinder displacement | 27 cm³ | 27 cm³ |
Output shaft power1 | 1.48 hp | 1.48 hp |
| Torque, max. | 1.28 Nm | 1.28 Nm |
| Torque, max. at rpm | 6,000 rpm | 6,000 rpm |
| Clutch engagement speed (±120) | 4,200 rpm | 4,200 rpm |
| Electrode gap | 0.02 in | 0.02 in |
| Idling speed | 2,900 rpm | 2,900 rpm |
| Ignition module air gap | 0.02 in | 0.02 in |
| Maximum power speed | 13,500 rpm | 13,500 rpm |
| Oil pump type | Adjustable flow | Adjustable flow |
| Spark Plug | NGK CMR6A | NGK CMR6A |
| Equipment | ||
| Recommended bar length, min | 8 in | 8 in |
| Pitch | 3/8" mini | 3/8" mini |
| Recommended bar length, max | 12 in | 12 in |
| Chain type | S93G | S93G |
| Bar length | 30 cm | 30 cm |
| Bar length (inch) | 12 in | 12 in |
| Sprocket type | Spur | Spur |
| Gauge | .050" | .050" |
| Dimensions | ||
| Weight (excl. cutting equipment) | 5.95 lbs | 5.95 lbs |
| Sound and noise | ||
| Sound pressure level at operators ear | 98 dB(A) | 98 dB(A) |
| Sound power level, guaranteed (LWA) | 111 dB(A) | 111 dB(A) |
| Sound power level, measured | 110 dB(A) | 110 dB(A) |
| Vibration | ||
| Equivalent vibration level (ahv, eq) rear handle | 5.2 m/s² | 5.2 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 4.9 m/s² | 4.9 m/s² |
| Lubricant | ||
| Oil tank volume | 0.36 US pint | 0.36 US pint |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | ||
Exhaust emissions (CO₂ EU V)2 | 850 g/kWh | |
