Specs
Key Specs
| Engine description | JD14 (B20 diesel compatible) | |||
|---|---|---|---|---|
| Engine displacement | 13.6 L 827 cu in. | |||
| Rated engine power | 434 kW 590 hp | |||
| Maximum engine power | 477 kW 649 hp | |||
| Rated PTO power (hp SAE) | 249 kW 335 hp | |||
| Maximum PTO power | ||||
| Transmission type | John Deere e18™ 18-speed PowerShift™ with Efficiency Manager™: 40 km/h 25 mph | |||
| Hydraulic pump rated output | Standard: 208 L/min 55 gpm Optional: 416 L/min 110 gpm | |||
| Rear hitch category (SAE designation) | Category 4N/N: 6804 kg 15,000 lb Category 4N/N: 9072 kg 20,000 lb | |||
| Base machine weight | 21,512 kg 47,326 lb | |||
| Maximum engine power PS (hp ISO) at max engine speed (EU 2016/1628) | ||||
| Rated engine power PS (hp ISO) at rated engine speed (EU 2016/1628) |
Engine specifications
| Description | JD14 (B20 diesel compatible) | |||
|---|---|---|---|---|
| Engine type | In-line six, four valve | |||
| Engine family | MJDXL13.5334 | |||
| Rated speed | 2100 rpm | |||
| Aspiration | Dual series turbocharger with fixed geometry first stage and wastegated second stage; air-to-air aftercooling and cooled exhaust gas recirculation (EGR) | |||
| Cylinders liners | Wet-sleeve | |||
| Emission level | Final Tier 4 (FT4) | |||
| After treatment type | Diesel oxidation catalyst (DOC)/selective catalytic reduction (SCR) | |||
| Displacement | 13.6 L 827 cu in. |
