Specs
Technical specifications
| Tractors Model | T3035  | T3025 | 4215 |
Engine manufacturer | TYM T1700N6 | TYM T1700N6 | TYM T2000N2 |
Engine power | 35 hp | 26.2 kW | 24 hp | 18 kW | 41 hp | 30.6 kW |
Rated engine speed | 2100 rpm | 2100 rpm | 2600 rpm |
Displacement | 104.5 cu. in. | 1744 cc | 104.5 cu. in. | 1714 cc | 139.5 cu. in. | 2287 cc |
No. of speeds | T3035R: F12 x F12 T3035H: 3-Range | T3025R: F12 x F12 T3025H: 3-Range | 4215R: F12 x R12 4215H: 3-Range |
Hitch lift capacity | 3307 lb | 1500 kg | 3307 lb | 1500 kg | 3306 lb | 1500 kg |
PTO rear | 540 rpm | 540 rpm | 540 rpm |
Fuel tank | 8.7 gal | 33 L | 8.7 gal | 33 L | 7.1 gal | 27 L |
Overall length with 3-point hitch | 120.9 in. | 3071 mm | 121 in. | 3071 mm | 120.9 in. | 3071 mm |
Overall width | 56.3 in. | 1430 mm | 56.3 in. | 1430 mm | 56.3 in. | 1430 mm |
Wheelbase | 65.7 in. | 1670 mm | 65.7 in. | 1670 mm | 65.7 in. | 1670 mm |
Height to top of ROPS | 97.3 in. | 2471 mm | 97.2 in. | 2471 mm | 97.3 in. | 2471 mm |
Min. ground clearance | 14.4 in. | 366 mm | 14.4 in. | 366 mm | 14.4 in. | 366 mm |
Weight with ROPS | 1347 kg | 2969.6 lb | 1347 kg | 2969.6 lb | 4215R: 3278 lb | 1487 kg 4215H: 3258 lb | 1478 kg |
R1 Agricultural - Front | 8-16 | 8-16 | 8-16 |
R1 Agricultural - Rear | 12.4-24 | 12.4-24 | 12.4-24 |
| Download | Technical Brochure | Technical Brochure | Technical Brochure |
