Specs
Frame
- Steel grade 44W and 50W
- Weight 2,100 lbs
- Max capacity with legs in stationary mode : 10,500 lbs
Mobile unit
- Towing capcity : Maximum 4,800 lbs
- Axle capacity with wheel : 2,000 lbs @ 25 km/h
- 2 inch tow bar with safety chains
Rollers & chain conveyor
- Maximum weight to drive the chain conveyor : 4,200 lbs
- Maximum weight to drive the rollers conveyor : 1,950 lbs
Dimensions
- Width of 90 inches
- Overall length of 210 inches
- Height of 47 inches
