Vermeer RR140 Rotary Rake

Contact us for price

Stock status: Call Store for Availability

Designed for operators focused on both speed and high-quality performance in a variety of crops
Versatile, side-delivery rotary rake
Achieve a light, fluffy windrow with minimal crop roping

Specs

Dimensions and Weights
- Raking width minimum 12.7 ft 3.9 m
- Raking width maximum 15.1 ft 4.6 m
- Windrow width minimum 28 in 71.1 cm
- Windrow width maximum 55 in 139.7 cm
- Transport Width 6.6 ft 2 m
- Transport Length 16.4 ft 5 m
- Transport Height 8.5 ft 2.6 m
- Total Weight 1676 lbs 760.2 kg
- Tongue Weight 221 lbs 100.2 kg
- Transport tire size 18 x 8.5-8
- Drive PTO, 540 rpm
Raking components
- Rotor diameter 135 in 342.9 cm
- Number of tine arms 11
- Number of double tines per arm 4
Tractor Requirements
- PTO horsepower minimum 30 hp 22.4 kw
- Hydraulic Type 1 single-acting
- Hydraulic Pressure 1800 psi 124.1 bar
- Hydraulic flow rate 8 gpm 30.3 L/min
