Specs
Operating Weight
- Net, unloaded – Box Shape
- 5,843 lbs
- 2,650 kg
- Net, unloaded – V Shape
- 6,317 lbs
- 2,865 kg
Transmission
- Type
- Variable Speed 2 Pump, 2 Motor Hydrostatic (HST)
- 2 Motor Hydrostatic (HST)
This div for css purpose only
Undercarriage
- Track Type
- Steel-Reinforced Rubber Track
- Steel-Reinforced Rubber Track
- Track Width
- 1’1″
- 320 mm
- Min. Ground Clearance – Bow Shape
- 10″
- 265 mm
- Min. Ground Clearance – V Shape
- 11″
- 280 mm
- Ground Contact Pressure – Bow Shape w/o load
- 4.0 PSI
- 27.5 kPa
- Ground Contact Pressure – Bow Shape w/ load
- 4.3 PSI
- 29.8 kPa
- Ground Contact Pressure – V Shape w/o Load
- 7.8 PSI
- 53.5 kPa
- Ground Contact Pressure – V Shape w/load
- 8.1 PSI
- 55.7 kPa
Performance
- Max. Payload – One-way Dump Type
- 5,512 lbs
- 2,500 kg
- Max. Dumping Angle – One-way Dump Type
- 58°
- 58°
- Max. Dumping Angle – Swivel-dump Type
- 85°
- 85°
- Dump Clearance – One-way Dump Type
- 1’6″
- 455 mm
- Dump Clearance – Swivel-dump Type
- 2’5″
- 730 mm
- Dump Body Capacity Struck – One-way Dump Type
- 1.15 yd³
- 0.88 m³
- Dump Body Capacity Heaped – Swivel-dump Type
- 1.47 yd³
- 1.13 m³
- Dump Body Capacity Struck – One-way Dump Type
- 1.62 yd³
- 1.24 m³
- Dump Body Capacity Heaped – Swivel-dump Style
- 1.96 yd³
- 1.50 m³
- Travel Speed – Forward
- Low Speed 0-3.5 mph / High Speed 0-6.8 mph
- Low Speed 0-5.7 km/h / High Speed 0-11.0 km/h
- Travel Speed – Reverse
- Low Speed 0-3.5 mph / High Speed 0-6.8 mph
- Low Speed 0-5.7 km/h / High Speed 0-11.0 km/h
