Specs
Operating Weight
- Net, unloaded – Box Shape
- 12,633 lbs
- 5,730 kg
- Net, unloaded – V Shape
- 13,360 lbs
- 6,060 kg
Transmission
- Type
- Variable Speed 2 Pump, 2 Motor Hydrostatic (HST)
- 2 Motor Hydrostatic (HST)
This div for css purpose only
Undercarriage
- Track Type
- Steel-Reinforced Rubber Track
- Steel-Reinforced Rubber Track
- Track Width
- 1’6″
- 450 mm
- Min. Ground Clearance
- 1’5″
- 435 mm
- Ground Contact Pressure – Bow Shape w/o load
- 3.4 PSI
- 23.5 kPa
- Ground Contact Pressure – Bow Shape w/ load
- 5.7 PSI
- 39.5 kPa
- Ground Contact Pressure – V Shape w/o Load
- 3.6 PSI
- 24.9 kPa
- Ground Contact Pressure – V Shape w/Load
- 5.7 PSI
- 39.5 kPa
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
Performance
- Max. Payload – Bow Shape
- 8,379 lbs
- 3,800 kg
- Max. Payload – V Shape
- 7,718 lbs
- 3,500 kg
- Max. Dumping Angle – Bow Shape
- 65°
- 65°
- Max. Dumping Angle – V Shape
- 65°
- 65°
- Dump Clearance – Bow Shape
- 2’2″
- 660 mm
- Dump Clearance – V Shape
- 2’11”
- 890 mm
- Dump Body Capacity Struck – Bow Shape
- 1.8 yd³
- 1.4 m³
- Dump Body Capacity Struck – V Shape
- 1.6 yd³
- 1.2 m³
- Max. Travel Speed – Bow Shape
- 5.9 mph
- 9.5 km/h
- Max. Travel Speed – V Shape
- 5.9 mph
- 9.5 km/h
